Git Submodule使用完整教程(小结)

这篇文章主要介绍了Git Submodule使用完整教程(小结),文中通过示例代码介绍的非常详细，对大家的学习或者工作具有一定的参考学习价值，需要的朋友们下面随着小编来一起学习学习吧。

自从看了蒋鑫的《Git权威指南》之后就开始使用Git Submodule功能，团队也都熟悉了怎么使用，多个子系统(模块)都能及时更新到最新的公共资源，把使用的过程以及经验和容易遇到的问题分享给大家。

Git Submodule功能刚刚开始学习可能觉得有点怪异，所以本教程把每一步的操作的命令和结果都用代码的形式展现给大家，以便更好的理解。

1.对于公共资源各种程序员的处理方式

每个公司的系统都会有一套统一的系统风格，或者针对某一个大客户的多个系统风格保持统一，而且如果风格改动后要同步到多个系统中;这样的需求几乎每个开发人员都遇到，下面看看各个层次的程序员怎么处理：

假如对于系统的风格需要几个目录：css、images、js。

普通程序员，把最新版本的代码逐个复制到每个项目中，如果有N个项目，那就是要复制N x 3次;如果漏掉了某个文件夹没有复制…@(&#@#。

文艺程序员，使用Git Submodule功能，执行：git submodule update，然后冲一杯咖啡悠哉的享受着。

引用一段《Git权威指南》的话： 项目的版本库在某些情况虾需要引用其他版本库中的文件，例如公司积累了一套常用的函数库，被多个项目调用，显然这个函数库的代码不能直接放到某个项目的代码中，而是要独立为一个代码库，那么其他项目要调用公共函数库该如何处理呢?分别把公共函数库的文件拷贝到各自的项目中会造成冗余，丢弃了公共函数库的维护历史，这显然不是好的方法。

2.开始学习Git Submodule

“工欲善其事，必先利其器”!

既然文艺程序员那么轻松就搞定了，那我们就把过程一一道来。

说明：本例采用两个项目以及两个公共类库演示对submodule的操作。因为在一写资料或者书上的例子都是一个项目对应1～N个lib，但是实际应用往往并不是这么简单。

2.1 创建Git Submodule测试项目

2.1.1 准备环境

➜ henryyan@hy-hp ~ pwd
/home/henryyan
mkdir -p submd/repos

创建需要的本地仓库：

cd ~/submd/repos
git –git-dir=lib1.git init –bare
git –git-dir=lib2.git init –bare
git –git-dir=project1.git init –bare
git –git-dir=project2.git init –bare

初始化工作区：

mkdir ~/submd/ws
cd ~/submd/ws

2.1.2 初始化项目

初始化project1：

➜ henryyan@hy-hp ~/submd/ws git clone ../repos/project1.git
Cloning into project1…
done.
warning: You appear to have cloned an empty repository.

➜ henryyan@hy-hp ~/submd/ws cd project1
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) echo “project1” > project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ ls
project-infos.txt

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git add project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
#
# Initial commit
#
# Changes to be committed:
# (use “git rm –cached …” to unstage)
#
# new file: project-infos.txt
#
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git commit -m “init project1”
[master (root-commit) 473a2e2] init project1
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git push origin master
Counting objects: 3, done.
Writing objects: 100% (3/3), 232 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/project1.git
* [new branch] master -> master

初始化project2：

➜ henryyan@hy-hp ~/submd/ws/project1 cd ..
➜ henryyan@hy-hp ~/submd/ws git clone ../repos/project2.git
Cloning into project2…
done.
warning: You appear to have cloned an empty repository.

➜ henryyan@hy-hp ~/submd/ws cd project2
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) echo “project2” > project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ ls
project-infos.txt

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git add project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git status
# On branch master
#
# Initial commit
#
# Changes to be committed:
# (use “git rm –cached …” to unstage)
#
# new file: project-infos.txt
#
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git commit -m “init project2”
[master (root-commit) 473a2e2] init project2
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git push origin master
Counting objects: 3, done.
Writing objects: 100% (3/3), 232 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/project2.git
* [new branch] master -> master

2.1.3 初始化公共类库

初始化公共类库lib1：

➜ henryyan@hy-hp ~/submd/ws git clone ../repos/lib1.git
Cloning into lib1…
done.
warning: You appear to have cloned an empty repository.
➜ henryyan@hy-hp ~/submd/ws cd lib1
➜ henryyan@hy-hp ~/submd/ws/lib1 git:(master) echo “I’m lib1.” > lib1-features
➜ henryyan@hy-hp ~/submd/ws/lib1 git:(master) ✗ git add lib1-features
➜ henryyan@hy-hp ~/submd/ws/lib1 git:(master) ✗ git commit -m “init lib1”
[master (root-commit) c22aff8] init lib1
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 lib1-features
➜ henryyan@hy-hp ~/submd/ws/lib1 git:(master) git push origin master
Counting objects: 3, done.
Writing objects: 100% (3/3), 227 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/lib1.git
* [new branch] master -> master

初始化公共类库lib2：

➜ henryyan@hy-hp ~/submd/ws/lib1 git:(master) cd ..
➜ henryyan@hy-hp ~/submd/ws git clone ../repos/lib2.git
Cloning into lib2…
done.
warning: You appear to have cloned an empty repository.
➜ henryyan@hy-hp ~/submd/ws cd lib2
➜ henryyan@hy-hp ~/submd/ws/lib2 git:(master) echo “I’m lib2.” > lib2-features
➜ henryyan@hy-hp ~/submd/ws/lib2 git:(master) ✗ git add lib2-features
➜ henryyan@hy-hp ~/submd/ws/lib2 git:(master) ✗ git commit -m “init lib2”
[master (root-commit) c22aff8] init lib2
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 lib2-features
➜ henryyan@hy-hp ~/submd/ws/lib2 git:(master) git push origin master
Counting objects: 3, done.
Writing objects: 100% (3/3), 227 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/lib2.git
* [new branch] master -> master

2.2 为主项目添加Submodules

2.2.1 为project1添加lib1和lib2

➜ henryyan@hy-hp ~/submd/ws/lib2 git:(master) cd ../project1
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ls
project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git submodule add ~/submd/repos/lib1.git libs/lib1
Cloning into libs/lib1…
done.
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git submodule add ~/submd/repos/lib2.git libs/lib2
Cloning into libs/lib2…
done.
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ ls
libs project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ ls libs
lib1 lib2

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
# Changes to be committed:
# (use “git reset HEAD …” to unstage)
#
# new file: .gitmodules
# new file: libs/lib1
# new file: libs/lib2
#

# 查看一下公共类库的内容

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cat libs/lib1/lib1-features
I’m lib1.
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cat libs/lib2/lib2-features
I’m lib2.

好了，到目前为止我们已经使用git submodule add命令为project1成功添加了两个公共类库(lib1、lib2)，查看了当前的状态发现添加了一个新文件(.gitmodules)和两个文件夹(libs/lib1、libs/lib2);那么新增的.gitmodules文件是做什么用的呢?我们查看一下文件内容便知晓了：

n@hy-hp ~/submd/ws/project1 git:(master) ✗ cat .gitmodules
[submodule “libs/lib1”]
path = libs/lib1
url = /home/henryyan/submd/repos/lib1.git
[submodule “libs/lib2”]
path = libs/lib2
url = /home/henryyan/submd/repos/lib2.git

原来如此，.gitmodules记录了每个submodule的引用信息，知道在当前项目的位置以及仓库的所在。

好的，我们现在把更改提交到仓库。

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git commit -a -m “add submodules[lib1,lib2] to project1”
[master 7157977] add submodules[lib1,lib2] to project1
3 files changed, 8 insertions(+), 0 deletions(-)
create mode 100644 .gitmodules
create mode 160000 libs/lib1
create mode 160000 libs/lib2

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (4/4), done.
Writing objects: 100% (4/4), 491 bytes, done.
Total 4 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (4/4), done.
To /home/henryyan/submd/ws/../repos/project1.git
45cbbcb..7157977 master -> master

假如你是第一次引入公共类库的开发人员，那么项目组的其他成员怎么Clone带有Submodule的项目呢，下面我们再clone一个项目讲解如何操作。

2.3 Clone带有Submodule的仓库

模拟开发人员B……

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cd ~/submd/ws
➜ henryyan@hy-hp ~/submd/ws git clone ../repos/project1.git project1-b
Cloning into project1-b…
done.
➜ henryyan@hy-hp ~/submd/ws cd project1-b
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git submodule
-c22aff85be91eca442734dcb07115ffe526b13a1 libs/lib1
-7290dce0062bd77df1d83b27dd3fa3f25a836b54 libs/lib2

看到submodules的状态是hash码和文件目录，但是注意前面有一个减号：-，含义是该子模块还没有检出。

OK，检出project1-b的submodules……

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git submodule init
Submodule ‘libs/lib1’ (/home/henryyan/submd/repos/lib1.git) registered for path ‘libs/lib1’
Submodule ‘libs/lib2’ (/home/henryyan/submd/repos/lib2.git) registered for path ‘libs/lib2’
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git submodule update
Cloning into libs/lib1…
done.
Submodule path ‘libs/lib1’: checked out ‘c22aff85be91eca442734dcb07115ffe526b13a1’
Cloning into libs/lib2…
done.
Submodule path ‘libs/lib2’: checked out ‘7290dce0062bd77df1d83b27dd3fa3f25a836b54’

读者可以查看：.git/config文件的内容，最下面有submodule的注册信息!

验证一下类库的文件是否存在：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) cat libs/lib1/lib1-features libs/lib2/lib2-features
I’m lib1.
I’m lib2.

上面的两个命令(git submodule init & update)其实可以简化，后面会讲到!

2.3 修改Submodule

我们在开发人员B的项目上修改Submodule的内容。

先看一下当前Submodule的状态：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) cd libs/lib1
➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git status
# Not currently on any branch.
nothing to commit (working directory clean)

为什么是Not currently on any branch呢?不是应该默认在master分支吗?别急，一一解答!

Git对于Submodule有特殊的处理方式，在一个主项目中引入了Submodule其实Git做了3件事情：

记录引用的仓库

记录主项目中Submodules的目录位置

记录引用Submodule的commit id

在project1中push之后其实就是更新了引用的commit id，然后project1-b在clone的时候获取到了submodule的commit id，然后当执行git submodule update的时候git就根据gitlink获取submodule的commit id，最后获取submodule的文件，所以clone之后不在任何分支上;但是master分支的commit id和HEAD保持一致。

查看~/submd/ws/project1-b/libs/lib1的引用信息：

➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 cat .git/HEAD
c22aff85be91eca442734dcb07115ffe526b13a1
➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 cat .git/refs/heads/master
c22aff85be91eca442734dcb07115ffe526b13a1

现在我们要修改lib1的文件需要先切换到master分支：

➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git checkout master
Switched to branch ‘master’
➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git:(master) echo “add by developer B” >> lib1-features
➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git:(master) ✗ git commit -a -m “update lib1-features by developer B”
[master 36ad12d] update lib1-features by developer B
1 files changed, 1 insertions(+), 0 deletions(-)

在主项目中修改Submodule提交到仓库稍微繁琐一点，在git push之前我们先看看project1-b状态：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)

libs/lib1 (new commits)状态表示libs/lib1有新的提交，这个比较特殊，看看project1-b的状态：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git diff
diff –git a/libs/lib1 b/libs/lib1
index c22aff8..36ad12d 160000
— a/libs/lib1
+++ b/libs/lib1
@@ -1 +1 @@
-Subproject commit c22aff85be91eca442734dcb07115ffe526b13a1
+Subproject commit 36ad12d40d8a41a4a88a64add27bd57cf56c9de2

从状态中可以看出libs/lib1的commit id由原来的c22aff85be91eca442734dcb07115ffe526b13a1更改为36ad12d40d8a41a4a88a64add27bd57cf56c9de2

注意：如果现在执行了git submodule update操作那么libs/lib1的commit id又会还原到c22aff85be91eca442734dcb07115ffe526b13a1，

这样的话刚刚的修改是不是就丢死了呢?不会，因为修改已经提交到了master分支，只要再git checkout master就可以了。

现在可以把libs/lib1的修改提交到仓库了：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ cd libs/lib1
➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git:(master) git push
Counting objects: 5, done.
Writing objects: 100% (3/3), 300 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/repos/lib1.git
c22aff8..36ad12d master -> master

现在仅仅只完成了一步，下一步要提交project1-b引用submodule的commit id：

➜ henryyan@hy-hp ~/submd/ws/project1-b/libs/lib1 git:(master) cd ~/submd/ws/project1-b
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git add -u
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git commit -m “update libs/lib1 to lastest commit id”
[master c96838a] update libs/lib1 to lastest commit id
1 files changed, 1 insertions(+), 1 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (3/3), done.
Writing objects: 100% (3/3), 395 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/project1.git
7157977..c96838a master -> master

OK，大功高成，我们完成了Submodule的修改并把libs/lib1的最新commit id提交到了仓库。

接下来要看看project1怎么获取submodule了。

2.4 更新主项目的Submodules

好的，让我们先进入project1目录同步仓库：

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) cd ../project1
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git pull
remote: Counting objects: 5, done.
remote: Compressing objects: 100% (3/3), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/ws/../repos/project1
7157977..c96838a master -> origin/master
Updating 7157977..c96838a
Fast-forward
libs/lib1 | 2 +-
1 files changed, 1 insertions(+), 1 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)

我们运行了git pull命令和git status获取了最新的仓库源码，然后看到了状态时modified，这是为什么呢?

我们用git diff比较一下不同：

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git diff
diff –git a/libs/lib1 b/libs/lib1
index 36ad12d..c22aff8 160000
— a/libs/lib1
+++ b/libs/lib1
@@ -1 +1 @@
-Subproject commit 36ad12d40d8a41a4a88a64add27bd57cf56c9de2
+Subproject commit c22aff85be91eca442734dcb07115ffe526b13a1
从diff的结果分析出来时因为submodule的commit id更改了，我们前面刚刚讲了要在主项目更新submodule的内容首先要提交submdoule的内容，然后再更新主项目中引用的submodulecommit id；现在我们看到的不同就是因为刚刚更改了project1-b的submodule commit id；好的，我来学习一下怎么更新project1的公共类库。

follow me……

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git submodule update
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)

为什么没有更新?git submodule update命令不是更新子模块仓库的吗?

别急，先听我解释;因为子模块是在project1中引入的，git submodule add ~/submd/repos/lib1.git libs/lib1命令的结果，操作之后git只是把lib1的内容clone到了project1中，但是没有在仓库注册，证据如下：

➜ henryyan@hy-hp ~/submd2/ws/project1 git:(master) ✗ cat .git/config
[core]
repositoryformatversion = 0
filemode = true
bare = false
logallrefupdates = true
[remote “origin”]
fetch = +refs/heads/*:refs/remotes/origin/*
url = /home/henryyan/submd/ws/../repos/project1.git
[branch “master”]
remote = origin
merge = refs/heads/master

我们说过git submodule init就是在.git/config中注册子模块的信息，下面我们试试注册之后再更新子模块：

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git submodule init
Submodule ‘libs/lib1’ (/home/henryyan/submd/repos/lib1.git) registered for path ‘libs/lib1’
Submodule ‘libs/lib2’ (/home/henryyan/submd/repos/lib2.git) registered for path ‘libs/lib2’
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git submodule update
remote: Counting objects: 5, done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/repos/lib1
c22aff8..36ad12d master -> origin/master
Submodule path ‘libs/lib1′: checked out ’36ad12d40d8a41a4a88a64add27bd57cf56c9de2’

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cat .git/config
[core]
repositoryformatversion = 0
filemode = true
bare = false
logallrefupdates = true
[remote “origin”]
fetch = +refs/heads/*:refs/remotes/origin/*
url = /home/henryyan/submd/ws/../repos/project1.git
[branch “master”]
remote = origin
merge = refs/heads/master
[submodule “libs/lib1”]
url = /home/henryyan/submd/repos/lib1.git
[submodule “libs/lib2”]
url = /home/henryyan/submd/repos/lib2.git

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cat libs/lib1/lib1-features
I’m lib1.
add by developer B

上面的结果足以证明刚刚的推断，所以记得当需要更新子模块的内容时请先确保已经运行过git submodule init。

2.5 为project2添加lib1和lib2

这个操作对于读到这里的你来说应该是轻车熟路了，action：

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cd ~/submd/ws/project2
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git submodule add ~/submd/repos/lib1.git libs/lib1
Cloning into libs/lib1…
done.
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git submodule add ~/submd/repos/lib2.git libs/lib2
zsh: correct ‘libs/lib2’ to ‘libs/lib1’ [nyae]? n
Cloning into libs/lib2…
done.
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ ls
libs project-infos.txt
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git submodule init
Submodule ‘libs/lib1’ (/home/henryyan/submd/repos/lib1.git) registered for path ‘libs/lib1’
Submodule ‘libs/lib2’ (/home/henryyan/submd/repos/lib2.git) registered for path ‘libs/lib2’

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git status
# On branch master
# Changes to be committed:
# (use “git reset HEAD …” to unstage)
#
# new file: .gitmodules
# new file: libs/lib1
# new file: libs/lib2
#
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git commit -a -m “add lib1 and lib2”
[master 8dc697f] add lib1 and lib2
3 files changed, 8 insertions(+), 0 deletions(-)
create mode 100644 .gitmodules
create mode 160000 libs/lib1
create mode 160000 libs/lib2
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (4/4), done.
Writing objects: 100% (4/4), 471 bytes, done.
Total 4 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (4/4), done.
To /home/henryyan/submd/ws/../repos/project2.git
6e15c68..8dc697f master -> master

我们依次执行了添加submodule并commit和push到仓库，此阶段任务完成。

2.6 修改lib1和lib2并同步到project1和project2

假如开发人员C同时负责project1和project2，有可能在修改project1的某个功能的时候发现lib1或者lib2的某个组件有bug需要修复，这个需求多模块和大型系统中经常遇到，我们应该怎么解决呢?

假如我的需求如下：

在lib1中添加一个文件：README，用来描述lib1的功能

在lib2中的lib2-features文件中添加一写文字：学习Git submodule的修改并同步功能

2.6.1 在lib1中添加一个文件：README

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) cd libs/lib1
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib1 git:(master) echo “lib1 readme contents” > README
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib1 git:(master) ✗ git add README
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib1 git:(master) ✗ git commit -m “add file README”
[master 8c666d8] add file README
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 README
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib1 git:(master) git push
Counting objects: 4, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (2/2), done.
Writing objects: 100% (3/3), 310 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/repos/lib1.git
36ad12d..8c666d8 master -> master

前面提到过现在仅仅只完成了一部分，我们需要在project2中再更新lib1的commit id：

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git add libs/lib1
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git commit -m “update lib1 to lastest commit id”
[master ce1f3ba] update lib1 to lastest commit id
1 files changed, 1 insertions(+), 1 deletions(-)

我们暂时不push到仓库，等待和lib2的修改一起push。

2.6.2 在lib2中的lib2-features文件添加文字

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) cd libs/lib2
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) echo “学习Git submodule的修改并同步功能” >> lib2-features
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) ✗ git add lib2-features
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) ✗ git commit -m “添加文字：学习Git submodule的修改并同步功能”
[master e372b21] 添加文字：学习Git submodule的修改并同步功能
1 files changed, 1 insertions(+), 0 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (2/2), done.
Writing objects: 100% (3/3), 376 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/repos/lib2.git
7290dce..e372b21 master -> master

➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) echo “学习Git submodule的修改并同步功能” >> lib2-features
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) ✗ git add lib2-features
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) ✗ git commit -m “添加文字：学习Git submodule的修改并同步功能”
[master e372b21] 添加文字：学习Git submodule的修改并同步功能
1 files changed, 1 insertions(+), 0 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (2/2), done.
Writing objects: 100% (3/3), 376 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/repos/lib2.git
7290dce..e372b21 master -> master
➜ henryyan@hy-hp ~/submd/ws/project2/libs/lib2 git:(master) cd –
~/submd/ws/project2
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git status
# On branch master
# Your branch is ahead of ‘origin/master’ by 1 commit.
#
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib2 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git add libs/lib2
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) ✗ git commit -m “update lib2 to lastest commit id”
[master df344c5] update lib2 to lastest commit id
1 files changed, 1 insertions(+), 1 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git status
# On branch master
# Your branch is ahead of ‘origin/master’ by 2 commits.
#
nothing to commit (working directory clean)
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git push
Counting objects: 8, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (6/6), done.
Writing objects: 100% (6/6), 776 bytes, done.
Total 6 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (6/6), done.
To /home/henryyan/submd/ws/../repos/project2.git
8dc697f..df344c5 master -> master

2.7 同步project2的lib1和lib2的修改到project1

现在project2已经享受到了最新的代码带来的快乐，那么既然project1和project2属于同一个风格，或者调用同一个功能，要让这两个(可能几十个)项目保持一致。

➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) cd ../project1
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git pull
Already up-to-date.

看看上面的结果对吗?为什么lib1和lib2更新了但是没有显示new commits呢?说到这里我记得刚刚开始学习的时候真得要晕死了，Git跟我玩捉迷藏游戏，为什么我明明提交了但是从project1更新不到任何改动呢?

帮大家分析一下问题，不过在分析之前先看看当前(project1和project2)的submodule状态：

# project2 的状态，也就是我们刚刚修改后的状态
➜ henryyan@hy-hp ~/submd/ws/project2 git:(master) git submodule
8c666d86531513dd1aebdf235f142adbac72c035 libs/lib1 (heads/master)
e372b21dffa611802c282278ec916b5418acebc2 libs/lib2 (heads/master)

# project1 的状态，等待更新submodules
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git submodule
36ad12d40d8a41a4a88a64add27bd57cf56c9de2 libs/lib1 (remotes/origin/HEAD)
7290dce0062bd77df1d83b27dd3fa3f25a836b54 libs/lib2 (heads/master)

两个项目有两个区别：

commit id各不相同

libs/lib1所处的分支不同

2.7.1 更新project1的lib1和lib2改动

我们还记得刚刚在project2中修改的时候把lib1和lib2都切换到了master分支，目前project1中的lib1不在任何分支，我们先切换到master分支：

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) cd libs/lib1
➜ henryyan@hy-hp ~/submd/ws/project1/libs/lib1 git checkout master
Previous HEAD position was 36ad12d… update lib1-features by developer B
Switched to branch ‘master’
Your branch is behind ‘origin/master’ by 1 commit, and can be fast-forwarded.
➜ henryyan@hy-hp ~/submd/ws/project1/libs/lib1 git:(master) git pull
remote: Counting objects: 4, done.
remote: Compressing objects: 100% (2/2), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/repos/lib1
36ad12d..8c666d8 master -> origin/master
Updating c22aff8..8c666d8
Fast-forward
README | 1 +
lib1-features | 1 +
2 files changed, 2 insertions(+), 0 deletions(-)
create mode 100644 README
➜ henryyan@hy-hp ~/submd/ws/project1/libs/lib1 git:(master)

果不其然，我们看到了刚刚在project2中修改的内容，同步到了project1中，当然现在更新了project1的lib1，commit id也会随之变动：

➜ henryyan@hy-hp ~/submd/ws/project1/libs/lib1 git:(master) cd ../../
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git diff
diff –git a/libs/lib1 b/libs/lib1
index 36ad12d..8c666d8 160000
— a/libs/lib1
+++ b/libs/lib1
@@ -1 +1 @@
-Subproject commit 36ad12d40d8a41a4a88a64add27bd57cf56c9de2
+Subproject commit 8c666d86531513dd1aebdf235f142adbac72c035

现在最新的commit id和project2目前的状态一致，说明真的同步了;好的，现在可以使用相同的办法更新lib2了：

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ cd libs/lib2
➜ henryyan@hy-hp ~/submd/ws/project1/libs/lib2 git:(master) git pull
remote: Counting objects: 5, done.
remote: Compressing objects: 100% (2/2), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/repos/lib2
7290dce..e372b21 master -> origin/master
Updating 7290dce..e372b21
Fast-forward
lib2-features | 1 +
1 files changed, 1 insertions(+), 0 deletions(-)

2.7.2 更新project1的submodule引用

在2.7.1中我们更新了project1的lib1和lib2的最新版本，现在要把最新的commit id保存到project1中以保持最新的引用。

➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
# modified: libs/lib2 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) ✗ git commit -a -m “update lib1 and lib2 commit id to new version”
[master 8fcca50] update lib1 and lib2 commit id to new version
2 files changed, 2 insertions(+), 2 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project1 git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (3/3), done.
Writing objects: 100% (3/3), 397 bytes, done.
Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
To /home/henryyan/submd/ws/../repos/project1.git
c96838a..8fcca50 master -> master

2.8 更新project1-b项目的子模块(使用脚本)

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git pull
remote: Counting objects: 5, done.
remote: Compressing objects: 100% (3/3), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/ws/../repos/project1
c96838a..8fcca50 master -> origin/master
Updating c96838a..8fcca50
Fast-forward
libs/lib1 | 2 +-
libs/lib2 | 2 +-
2 files changed, 2 insertions(+), 2 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git status
# On branch master
# Changes not staged for commit:
# (use “git add …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# modified: libs/lib1 (new commits)
# modified: libs/lib2 (new commits)
#
no changes added to commit (use “git add” and/or “git commit -a”)

Git提示lib1和lib2有更新内容，这个判断的依据来源于submodule commit id的引用。

现在怎么更新呢?难道还是像project1中那样进入子模块的目录然后git checkout master，接着git pull?

而且现在仅仅才两个子模块、两个项目，如果在真实的项目中使用的话可能几个到几十个不等，再加上N个submodule，自己算一下要怎么更新多少个submodules?

例如笔者现在做的一个项目有5个web模块，每个web模块引用公共的css、js、images、jsp资源，这样就有20个submodule需要更新!!!

工欲善其事，必先利其器，写一个脚本代替手动任务。

2.8.1 牛刀小试

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ grep path .gitmodules | awk ‘{ print $3 }’ > /tmp/study-git-submodule-dirs
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ cat /tmp/study-git-submodule-dirs
libs/lib1
libs/lib2

我们通过分析.gitmodules文件得出子模块的路径，然后就可以根据这些路径进行更新。

2.8.2 上路

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ mkdir bin
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ vi bin/update-submodules.sh

把下面的脚本复制到bin/update-submodules.sh中：

#!/bin/bash
grep path .gitmodules | awk ‘{ print $3 }’ > /tmp/study-git-submodule-dirs

# read
while read LINE
do
echo $LINE
(cd ./$LINE && git checkout master && git pull)
done < /tmp/study-git-submodule-dirs

稍微解释一下上面的脚本执行过程：

首先把子模块的路径写入到文件/tmp/study-git-submodule-dirs中;

然后读取文件中的子模块路径，依次切换到master分支(修改都是在master分支上进行的)，最后更新最近改动。

2.8.3 2013-01-19更新

网友@紫煌给出了更好的办法，一个命令就可以代替上面的bin/update-submodules.sh的功能：

git submodule foreach git pull

此命令也脚本一样，循环进入(enter)每个子模块的目录，然后执行foreach后面的命令。

该后面的命令可以任意的，例如 git submodule foreach ls -l 可以列出每个子模块的文件列表

2.8.3 体验工具带来的便利

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git submodule
+36ad12d40d8a41a4a88a64add27bd57cf56c9de2 libs/lib1 (heads/master)
+7290dce0062bd77df1d83b27dd3fa3f25a836b54 libs/lib2 (heads/master)

# 添加执行权限
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ chmod +x ./bin/update-submodules.sh
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ ./bin/update-submodules.sh
libs/lib1
Already on ‘master’
remote: Counting objects: 4, done.
remote: Compressing objects: 100% (2/2), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/repos/lib1
36ad12d..8c666d8 master -> origin/master
Updating 36ad12d..8c666d8
Fast-forward
README | 1 +
1 files changed, 1 insertions(+), 0 deletions(-)
create mode 100644 README
libs/lib2
Switched to branch ‘master’
remote: Counting objects: 5, done.
remote: Compressing objects: 100% (2/2), done.
remote: Total 3 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (3/3), done.
From /home/henryyan/submd/repos/lib2
7290dce..e372b21 master -> origin/master
Updating 7290dce..e372b21
Fast-forward
lib2-features | 1 +
1 files changed, 1 insertions(+), 0 deletions(-)
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git submodule
8c666d86531513dd1aebdf235f142adbac72c035 libs/lib1 (heads/master)
e372b21dffa611802c282278ec916b5418acebc2 libs/lib2 (heads/master)

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git status
# On branch master
# Untracked files:
# (use “git add …” to include in what will be committed)
#
# bin/
nothing added to commit but untracked files present (use “git add” to track)

更新之后的两个变化：

git submodule的结果和project2的submodule commit id保持一致;

project1-b不再提示new commits了。

现在可以把工具添加到仓库了，当然你可以很骄傲的分享给其他项目组的同事。

➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git add bin/update-submodules.sh
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) ✗ git commit -m “添加自动更新submodule的快捷脚本^_^”
[master 756e788] 添加自动更新submodule的快捷脚本^_^
1 files changed, 9 insertions(+), 0 deletions(-)
create mode 100755 bin/update-submodules.sh
➜ henryyan@hy-hp ~/submd/ws/project1-b git:(master) git push
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (3/3), done.
Writing objects: 100% (4/4), 625 bytes, done.
Total 4 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (4/4), done.
To /home/henryyan/submd/ws/../repos/project1.git
8fcca50..756e788 master -> master

2.9 新进员工加入团队，一次性Clone项目和Submodules

一般人使用的时候都是使用如下命令：

git clone /path/to/repos/foo.git
git submodule init
git submodule update

新员工不耐烦了，嘴上不说但是心里想：怎么那么麻烦?

上面的命令简直弱暴了，直接一行命令搞定：

git clone –recursive /path/to/repos/foo.git

–recursive参数的含义：可以在clone项目时同时clone关联的submodules。

git help 对其解释：

–recursive, –recurse-submodules

After the clone is created, initialize all submodules within, using their default settings. This is equivalent to running git

submodule update –init –recursive immediately after the clone is finished. This option is ignored if the cloned repository

does not have a worktree/checkout (i.e. if any of –no-checkout/-n, –bare, or –mirror is given)

2.9.1 使用一键方式克隆project2

➜ henryyan@hy-hp ~/submd/ws git clone –recursive ../repos/project2.git project2-auto-clone-submodules
Cloning into project2-auto-clone-submodules…
done.
Submodule ‘libs/lib1’ (/home/henryyan/submd/repos/lib1.git) registered for path ‘libs/lib1’
Submodule ‘libs/lib2’ (/home/henryyan/submd/repos/lib2.git) registered for path ‘libs/lib2’
Cloning into libs/lib1…
done.
Submodule path ‘libs/lib1’: checked out ‘8c666d86531513dd1aebdf235f142adbac72c035’
Cloning into libs/lib2…
done.
Submodule path ‘libs/lib2’: checked out ‘e372b21dffa611802c282278ec916b5418acebc2’
舒服……

3.移除Submodule

牢骚：搞不明白为什么git不设计一个类似：git submodule remove的命令呢?

我们从project1.git克隆一个项目用来练习移除submodule：

➜ henryyan@hy-hp ~/submd/ws git clone –recursive ../repos/project1.git project1-remove-submodules
Cloning into project1-remove-submodules…
done.
Submodule ‘libs/lib1’ (/home/henryyan/submd/repos/lib1.git) registered for path ‘libs/lib1’
Submodule ‘libs/lib2’ (/home/henryyan/submd/repos/lib2.git) registered for path ‘libs/lib2’
Cloning into libs/lib1…
done.
Submodule path ‘libs/lib1’: checked out ‘8c666d86531513dd1aebdf235f142adbac72c035’
Cloning into libs/lib2…
done.
Submodule path ‘libs/lib2’: checked out ‘e372b21dffa611802c282278ec916b5418acebc2’
➜ henryyan@hy-hp ~/submd/ws cd !$
➜ henryyan@hy-hp ~/submd/ws cd project1-remove-submodules

3.1 Step by

1、删除git cache和物理文件夹

➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) git rm -r –cached libs/
rm ‘libs/lib1’
rm ‘libs/lib2’
➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) ✗ rm -rf libs

2、删除.gitmodules的内容(或者整个文件) 因为本例只有两个子模块，直接删除文件：

➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) ✗ rm .gitmodules

如果仅仅删除某一个submodule那么打开.gitmodules文件编辑，删除对应submodule配置即可。

3、删除.git/config的submodule配置 源文件：

[core]
repositoryformatversion = 0
filemode = true
bare = false
logallrefupdates = true
[remote “origin”]
fetch = +refs/heads/*:refs/remotes/origin/*
url = /home/henryyan/submd/ws/../repos/project1.git
[branch “master”]
remote = origin
merge = refs/heads/master
[submodule “libs/lib1”]
url = /home/henryyan/submd/repos/lib1.git
[submodule “libs/lib2”]
url = /home/henryyan/submd/repos/lib2.git

删除后：

[core]
repositoryformatversion = 0
filemode = true
bare = false
logallrefupdates = true
[remote “origin”]
fetch = +refs/heads/*:refs/remotes/origin/*
url = /home/henryyan/submd/ws/../repos/project1.git
[branch “master”]
remote = origin
merge = refs/heads/master

4、提交更改

➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) ✗ git status
# On branch master
# Changes to be committed:
# (use “git reset HEAD …” to unstage)
#
# deleted: libs/lib1
# deleted: libs/lib2
#
# Changes not staged for commit:
# (use “git add/rm …” to update what will be committed)
# (use “git checkout — …” to discard changes in working directory)
#
# deleted: .gitmodules
#
➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) ✗ git add .gitmodules
➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) ✗ git commit -m “删除子模块lib1和lib2”
[master 5e2ee71] 删除子模块lib1和lib2
3 files changed, 0 insertions(+), 8 deletions(-)
delete mode 100644 .gitmodules
delete mode 160000 libs/lib1
delete mode 160000 libs/lib2
➜ henryyan@hy-hp ~/submd/ws/project1-remove-submodules git:(master) git push
Counting objects: 3, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (2/2), done.
Writing objects: 100% (2/2), 302 bytes, done.
Total 2 (delta 0), reused 0 (delta 0)
Unpacking objects: 100% (2/2), done.
To /home/henryyan/submd/ws/../repos/project1.git
756e788..5e2ee71 master -> master

4.结束语

对于Git Submodule来说在刚刚接触的时候多少会有点凌乱的赶紧，尤其是没有接触过svn:externals。

本文从开始创建项目到使用git submodule的每个步骤以及细节、原理逐一讲解，希望到此读者能驾驭它。

学会了Git submdoule你的项目中再也不会出现大量重复的资源文件、公共类库，更不会出现多个版本，甚至一个客户的多个项目风格存在各种差异。

来源：http://www.kafeitu.me/git/2012/03/27/git-submodule.html

拉取所有子模块

git submodule foreach git pull
git submodule foreach –recursive git submodule init
git submodule foreach –recursive git submodule update

到此这篇关于Git Submodule使用完整教程(小结)的文章就介绍到这了,更多相关Git Submodule使用内容请搜索脚本之家以前的文章或继续浏览下面的相关文章希望大家以后多多支持脚本之家!

文章转自脚本之家，原文链接：https://www.jb51.net/article/193194.htm
